HIOKI BT3563A Battery HiTester
Jual HIOKI BT3563A Battery HiTester
Designing automatic battery testing systems is easier and faster than ever before
• Double the total line resistance, so measurement errors are less likely to occur when using long measurement cables
• Stable operation regardless of increased total line resistance due to probe and relay degradation
• LAN is equipped as a standard for easy system design and layout, and excellent noise resistance for stable operation
• Improved electrostatic resistance as a countermeasure against electrostatic charges during battery transport on a production line
Key Features Hioki BT3563A Battery HiTester
• Simultaneous measurement of internal resistance and open circuit voltage.
• Fully automated production line testing of large packs for xEVs or large packs of up to 300 V.
• Resistance measurement ranges: 3 mΩ/30 mΩ/300 mΩ/3 Ω/30 Ω/300 Ω/3 kΩ
• Voltage measurement ranges: 6 V/60 V/300 V • Equipped with LAN
Basic specifications (Accuracy guarantee period: 1 year, Accuracy guarantee period after adjustment made by Hioki: 1 year)
| Resistance measurement ranges | 3 mΩ（Max. display: 3.1000 mΩ, resolution: 0.1 μΩ, measurement current: 100 mA） 30 mΩ（Max. display: 31.000 mΩ, resolution: 1 μΩ, measurement current: 100 mA） 300 mΩ（Max. display: 310.00 mΩ, resolution: 10 μΩ, measurement current: 10 mA） 3 Ω（Max. display: 3.1000 Ω, resolution: 100 μΩ, measurement current: 1 mA） 30 Ω（Max. display: 31.000 Ω, resolution: 1 mΩ, measurement current: 100 μA） 300 Ω（Max. display: 310.00 Ω, resolution: 10 mΩ, measurement current: 10 μA） 3 kΩ（Max. display: 3.1000 kΩ, resolution: 100 mΩ, measurement current: 10 μA） |
|---|
Basic accuracy: ±0.5% rdg ±10 dgt（3 mΩ range）, ±0.5% rdg ±5 dgt（30 mΩ range or more）
Measurement frequency: 1 kHz ±0.2 Hz
Measurement method: AC four-terminal methodVoltage measurement ranges6 V（Max. display: 6.00000 V, resolution: 10 μV）
60 V（Max. display: 60.0000 V, resolution: 100 μV）
300 V（Max. display: 300.000 V, resolution: 1 mV）
Basic accuracy: ±0.01% rdg. ±3 dgt.Response time10 msSampling periodΩ or V: 4 ms (EX.FAST), 12 ms (FAST), 35 ms (MEDIUM), 150 ms (SLOW)
ΩV: 8 ms (EX.FAST), 24 ms (FAST), 70 ms (MEDIUM), 253 ms (SLOW)FunctionsContact check, Zero adjustment (±1000 counts), Pulse measurement, Comparator (Hi/ IN/ Lo), Statistical calculations (Max. 30,000), Delay, Average, Panel saving/loading, Memory storage, LabVIEW® driverInterfacesLAN (TCP/IP, 10BASE-T/100BASE-TX)
RS-232C (Max. 38.4 kbps, Available as printer I/F)
EXT I/O (37-pin Handler interface)
Analog output (DC 0 V to 3.1 V)Power supply100 to 240 V AC, 50 Hz/60 Hz, 35 VA max.Dimensions and mass215 mm (8.46 in) W × 80 mm (3.15 in) H × 295 mm (11.61 in) D, 2.4 kg (84.7 oz)
